AiM MXS 1.3 TFT Digital Display and Data Logger
The MXS 1.3 dash logger has a 5" TFT display which has been designed to acquire and display data coming from the ECU.
Key Features :
5" compact TFT display
GPS Module
CAN output
6 configurable RGB LEDs
Two digital outputs
Wi-Fi connectivity
Integrated shift array
1,000+ industry-leading ECUs

AiM MXS 1.3 TFT Digital Display and Data Logger
The MXS 1.3 5" TFT compact Dash Logger is fully configurable and suitable for many different Motorsports. It has been designed to acquire and display data coming from the ECU. Analogue/digital inputs and predefined math channels. Performance and data acquired can also be incremented by adding up to eight expansion modules. The MXS 1.3 is a great choice for compact cockpit installations where space is at a premium.

Easy Connection
Connecting the MXS 1.3 dash to your ECU is simple. You can sample dozens of channels straight from the vehicles ECU. This is usually the quickest and easiest setup, needing only a cable connection to the ECU instead of multiple connections and analogue sensors. The sampled data will depend on your actual ECU but typically includes RPM, engine load, throttle position (TPS), oil, air, water temperature, oil pressure, battery voltage, speed, gear, lambda value (air/fuel ratio). The list of available ECU drivers is constantly updated and upgraded and includes approximately 1000+ different  ECUs.
Two Digital Outputs
MXS 1.3 features two digital outputs. Each of them can give an output of 1 amp at 12 volts. They can be configured to be turned on/off depending on the value of the analogue or digital inputs. They permit to automatically run external systems such as switching on/off additional lights, to activate/deactivate a cooling fan or circulation pumps when a certain event happens.
